Record phone calls without any apps or special equipment

This is all from memory so I hope it works. Mostly aimed at journalists working on a Macbook. Works with any phone that has a headphone jack. That includes all iPhones in existence and all Android or Windows phones I know of.

Total cost: $1 to $5, although chances are you might already have everything you need lying around the house or office.

Total time: 5 minutes unless you need to pop over to Radioshack or the supermarket for a stereo cable.

  1. Open the Audio MIDI Setup app (just do a Spotlight search for it, otherwise you’ll find it in Applications/Utilities).
  2. Click the + sign in the bottom left and choose “Create Aggregate Device”.
  3. Tick “Built-in Microphone” and “Built-in Output”.
  4. You can double-click the name in the left sidebar to rename it to something like “Phone Recording” instead of the default “Aggregate Device”.
  5. Close Audio MIDI Setup.
  6. Open Quicktime and go to File > New Audio Recording.
  7. Click the little white down arrow on the right of the recording window and choose your aggregate device under “Microphone”.
  8. Plug a stereo cable from your phone’s headphone jack into the audio input jack on your Mac. If it’s a new one there’s only one jack for both input and output - use that.
  9. Put your phone right in front your keyboard with its mic facing your mouth as much as possible.
  10. Press the record button on Quicktime.
  11. Dial the number on your phone and hit call - make sure you have your Mac speakers turned up enough so you can hear the voice of the other person coming through but not too much so that you get feedback.

If background noise or feedback is too much of a problem, or if you simply don’t want anyone else in the room to hear the other end of the conversation, you’ll have to use a headphone splitter ($4 on Amazon). Plug the single end of the splitter into your phone’s headphone jack. Plug your headphones into one of the splitter jacks and the stereo cable from your computer into the other splitter jack. Mute the speakers on your computer and put on your headphones.

If you can’t hear anything over the speakers, hold down the alt key on your keyboard and click the speaker icon in the Mac status bar. Make sure “External microphone” is checked under “Input Device” and “Internal Speakers” under “Output Device”.

If your voice is too low in the recorded audio, it’s because it isn’t reaching your Mac’s mic properly. The way this technique works is that your voice is captured both by the computer’s mic and your phone’s mic at the same time, so it’s important that they’re positioned right next to each other and you project your voice towards both devices.

Fix accented filenames on Linux with convmv

I’m working on a WordPress-powered site covering politics in Costa Rica. Today, an editor called me up asking why some images weren’t showing up in his browser, Safari 6.1.

The issue turned out to be caused by Unicode equivalence conflicts.

OS X normalises accented characters using Unicode NFD (Normalization Form Canonical Decomposition), whereas Linux and most other operating systems use NFC (Canonical Composition).

The editor had created files that contained an accented í on his Mac, then uploaded those to the WordPress media library. The file was saved to the filesystem on the Linux server as NFD and referenced in the WordPress database also using the original NFD filename. This caused two problems.

The first was that Safari was normalising the URL to NFC, requesting 140201LuisGuillermoSol%C3%ADs.jpg instead of LuisGuillermoSoli%CC%81s.jpg.

The second was that I couldn’t rename the file on the server filesystem. Any attempt at using mv to rename the offending files resulted in cannot stat errors.

The solution was multi fold. I first installed convmv (apt-get install convmv) and used the following command to rename the files in bulk.

convmv --nfc --nosmart --notest -r -i -f UTF-8 -t UTF-8 /path/to/files

After doing that, I was able to rename the files using mv.

Then I manually edited the entries in the WordPress database to remove the accents. Panic over.

To avoid the issue in the long term, I added the following filter to the theme’s functions.php:

add_filter('sanitize_file_name', function($filename) { return remove_accents($filename); }, 10);

remove_accents is a WordPress function.

Automatic routing

Most of the time, standards make life easier. I was writing the routing configuration for a new web app. My configuration looked something like the following. :d is a placeholder for an identifier.

{ "/files/": { "controller": "files", "methods": ["GET", "POST", "PUT"] }, "/files/:d": { "controller": "sources" "methods": ["GET", "DELETE", "PUT"] }, "/sources/:d/files/": { "controller": "sourceFiles" "methods": ["GET", "POST", "PUT", "DELETE"] } }

And so on.

Is listing the methods really necessary? My application uses URLs to represent resources and groups. File resources and groups or collections of file resources.

By ending a path with a trailing slash, we make it clear that it represents a collection. Without the trailing slash, it’s ambiguous whether the URL refers to a resource or a resource group.

The original paper on representational state transfer didn’t mention this. I think it’s a useful convention.

From there on it’s just a small step to put some heuristics in our router so that implied methods are wired up.

Routes should generally implement GET, HEAD and OPTIONS. So let’s start our routing logic with that. All routes should implement PUT and DELETE, so that’s easy too.

Note that implementing doesn’t necessarily mean that the method is allowed. For example, if your app doesn’t allow entire collections to be deleted, you could always reply to a DELETE on a collection like /files/ with 405 Method Not Allowed.

Routes with a trailing slash are collections, so those should support POST, which will be used to a create a new resource and add it to the collection in a non-idempotent way. That last bit means that the action can’t be repeated without side-effects - that is, that the end-state of the /files/ collection changes with every request because a new resource is created and added each time.

PUT on the collection would replace the entire thing. Again, although the router would implement the method, you could disallow it.

A URL without a trailing slash represents a single resource. Does it make sense to POST to that? Probably not, so our router would disallow that automatically. A PUT however, would be implemented as it’s used to update the resource from the client. You could respond with 401 Unauthorized if you require authentication for users to change things.

So there you have it. Routing heuristics for the peoples.

Automating choropleth mapmaking in the newsroom

Last weekend I launched Tuanis, a web application for easily producing choropleth maps using Google Spreadsheets and bit of option toggling.

Here’s one example showing the tons of household and commercial waste produced per month in each canton.

The project started like this. For the past few months I’ve been working as a web developer at La Nación in Costa Rica. A few weeks ago, I made an SVG choropleth map for recycling statistics in Costa Rica. I wrote a Makefile that converted shapefiles from GADM.org to GeoJSON using GDAL’s ogr2ogr, then to TopoJSON.

On the browser side, I used d3 to generate the SVG from the built TopoJSON file on every client load and munge in the statistics from a CSV file that my journalist colleague Hassel Fallas produced. Obviously, this process is extremely inefficient. Never mind the fact that I kept thinking it could all be so easily automated.

While figuring out the automation, I came across Kartograph.py and realised that not only was this a better way to do produce an SVG, but I could automate the entire process so that journalists can generate and embed maps themselves.

My new Makefile runs Kartograph.py against the shapefiles and produces an optimized SVG, weighing in at about 70kb. The app’s single HTML page loads the SVG using an <object> tag which is then manipulating using JavaScript to change the fill colors when statistical data is loaded.

How is statistical data loaded? That’s the best bit. All you have to do is create a Google Spreadsheet and publish it to the Web. Paste the document URL into Tuanis and hit the load button. When it loads, select the canton ID and statistic fields from the dropdowns.

We use the HTML5 History API to change the URL as you manipulate the controls, so every time you change a setting or load a spreadsheet the URL changes too and anyone you send it to will see the exact same map.

As an added bonus, these permanent URLs enable the map to be easily embedded in any HTML page. Just grab the embed code from Tuanis and paste it into your application.

For the nerdier, the color sets come from a system called ColorBrewer, developed by Cynthia Brewer at Pennsylvania State University. In turn, we’re using Croma.js to provide the ColorBrewer color sets and manipulate the scales.

Oh, and the name “tuanis” means “awesome” in Central American slang.

Community detection with the offshore leaks data

Someone on the Internet ran an algorithm using iGraph that automatically assigns nodes to clusters based on whether they seem to be in a real-life community with each other or not.

What does this mean? A good way to understand this is using your friends on Facebook. As you go through life you meet people in groups, and these groups form separate clusters or communities. For example, your friends from high school form one cluster, your friends from college another cluster. When you start a new job all the new colleagues you add on Facebook become a new cluster.

One of the ways to visualize this is by clumping together nodes that are part of the same cluster and assigning them the same color. That’s what this person has done.

For example, the majority of the addresses in Mexico are all in San Pedro Garza Garcia, the wealthy suburb of Monterrey where Dionisio Garza Medina lives. Those addresses and the Grupo ALFA subsidiaries in the database, along with Garza Medina himself, are part of the same cluster.

If there are other clusters in Mexico then by visualizing them in this way we’d be able to see fairly quickly where they intersect, allowing you to see the big picture.

It gets even more interesting when you add time series. Because we have dates for the roles then we can build a progressive series of visualizations that show how the communities wax, wane, merge and divide over time.

For example, if when looking at the progression of visualizations we see that a cluster with a strong presence in Switzerland appears to explode in size at some point in time, then we can dive into the data and see that it happened when person X became the director of one of the Swiss entities. That could indicate that X was the go-between responsible for dealing with Portcullis TrustNet and that he or she hooked up all the other companies.

Sync your hosts file to the Android emulator with aemu

The Android emulator has become a lot more usable since the use of HAXM, but there are still a few annoyances, like the fact that the host OS’s ‘hosts’ file isn’t used during name resolution.

Editing the hosts file on the emulator itself is very difficult, time-consuming and error-prone. I really don’t want to have to do that every time I need to use the emulator to test a local host.

So I’ve written a bunch of tools for the emulator called aemu and one of the packaged tools is called aemu-hosts. It allows you to launch a virtual device and sync your hosts file to it in one command.

Also included is aemu-sms, which I’m using as a hacky way to ‘paste’ things into the running virtual device, as there’s no normal copy/paste functionality.

Resource groups in REST

Quoted from Programmers.

A URL that doesn’t end in a slash names a resource, while one that does is a resource group.

A GET of a URL with a slash on the end is supposed to list the resources available.

GET http://example.com/dogs/ /* List all the dogs resources */

A PUT on a URL with a slash is supposed to replace all the resources.

PUT http://example.com/dogs/ /* Replace all the dogs resources */

A DELETE on a URL with a slash is supposed to delete all the resources.

DELETE http://example.com/dogs/ /* Deletes all the dogs resources */

A POST on a URL with a slash is supposed to create a new resource that can then be subsequently accessed.

POST http://example.com/dogs/ /* Creates a new dogs resource (notice singular) */

To be conformant the new resource should be in this directory and the server should respond with 201 Created and a Location: /dogs/1 header field (or just 202 Accepted if the resource can’t be created before the response and you want to show a progress page).

Get the Android emulator running mega fast

This works on Mac, Windows and Linux.

Run android in the terminal to open the SDK application. Make sure Intel x86 Emulator Accelerator (HAXM) underneath Extras is installed. If not, install it. Then go to Tools → Manage AVDS….

Make sure the CPU/ABI field of your virtual device is set to Intel Atom (x86). You can even tick Use Host GPU in the settings for even more acceleration. Select it from the list and click Start….

If you see HAX is not working in the log output then you need to install the Intel Hardware Acceleration Execution Manager.

Once you’ve done that, try starting the virtual device again. You should now see HAX is working and emulator runs in fast virt mode in the log output.
